- Low profile with high gain， reading distance range up to 15m
- Maximum efficiency and performance across the entire frequency band
- Seamlessly compatible with different brand RFID readers
- Widely used in file cabinets, smart shelves, etc.
| Physical Specifications | |
|---|---|
| Weight: | 100g |
| Dimensions: | 200mmX200mmX22.5mm |
| Material: | PCB |
| Connector type / position: | SMA on the side |
| Operating Temperature: | -25 - +75°C |
| Storage Temperature: | -40 - +85°C |
| Electrical Specifications | |
| Frequency Range: | 840MHz~960MHz |
| Typical VSWR: | ≤1.5:1 |
| Gain: | 8dBi |
| H Beamwidth: | 70° |
| E Beamwidth: | 70° |
| Polarization: | Circular |
| Nominal Impedance: | 50 Ω |
